PTB750B-03-2-04-2 5.08mm Wire to Wire Connector

Product Item : PTB750B-03-2-04-2
Category： Connectors
Spacing: 5.08mm
Product description：PTB750B-03-2-04-2 5.08mm Wire to Wire Connector 4PIN 5.08mm PTB750B-03-2-04-2 Bule RoHS
Download Order online

Technical parameters	Values (range)
UL-Technical Data
Spacing：	5.00/5.08mm
Rated voltage：	300V
Rated current：	15A
Pressure line range：	12-30AWG
IEC-Technical Data
Overvoltage Category - Degree of pollution：	Level 3
Rated voltage：	250V,320V,630V
Rated impulse voltage：	4KV
Rated cross-section - rated current：	2.5mm/18A
Material
Insulating materials：	PA
Flammability rating：	UL94,V-0
Contact materials：	Brass
Contact point of coating：	Tin Plating
Other Information
PCB board aperture：
Strip length：	6.50mm
Screws \| Torque：	M3/5lbf.in
