Technical parameters
|
Values (range)
|
|---|---|
|
UL-Technical Data
|
|
| Spacing： | 5.00/5.08mm |
|
Rated voltage：
|
300V |
|
Rated current：
|
15A |
|
Pressure line range：
|
12-30AWG |
|
IEC-Technical Data
|
|
|
Overvoltage Category - Degree of pollution：
|
Level 3 |
|
Rated voltage：
|
250V,320V,630V |
|
Rated impulse voltage：
|
4KV |
|
Rated cross-section - rated current：
|
2.5mm/18A |
|
Material
|
|
|
Insulating materials：
|
PA |
|
Flammability rating：
|
UL94,V-0 |
|
Contact materials：
|
Brass |
|
Contact point of coating：
|
Tin Plating |
|
Other Information
|
|
|
PCB board aperture：
|
|
|
Strip length：
|
6.50mm |
|
Screws | Torque：
|
M3/5lbf.in |
